On-Premise Deployment
Minimum Hardware Requirement
| RAM | 16GB |
|---|---|
| CPU | 8vCPU |
| Hard disk | 100GB |
| Network ports (minimum 1Gbs) | TCP: 22, 80, 443,5000 |
Hardware Sizing
The following table shows the required specification of one server node that imports MetaDefender IT Access On Prem.
| Number of Device | Up to 10,000 | 10,000 to 20,000 |
|---|---|---|
| CPU | 8vCPU | 16vCPU |
| RAM | 16 GB | 32 GB |
| Hard disk capacity | 100GB | 500GB |
Ports used
The table below shows the default port configuration of MAOP. The listed ports must be available to start MetaDefender IT Access On Prem
| Component/ Service | Port | Notes | |
|---|---|---|---|
| Web Management Console | Web Management Console | TCP: 80, 443 | |
| SFTP | Download log | TCP: 22 | |
| Trigger general log | Trigger general log | TCP: 5000 |
Software Version
| Name | Version | Notes |
|---|---|---|
| OVA hardware compatible version | ESXi 8.0 and later (VM version 20) | Enable 3D Support (3D Graphics) |
